SIDUR 3401 Steel Plates (1.3401 / 12MN / A128 grade A)
Designation by Standards :
| Brand Name | Ravne | Mat. No. | DIN | AISI/SAE |
| SIDUR 3401 | 12MN | 1.3401 | X120Mn12 | A128 grade A |
Chemical Composition (in weight %) :
| C | Si | Mn | Cr | Mo | Ni | V | W | Others |
| 1.2 | 0.4 | 12.5 | max. 1.50 | - | - | - | - | - |
Description of SIDUR 3401 Plates :
Austenitic Mn-steel. The well-known Hadfield steel still has broad applications in the mineral processing industry. Especially under impact loading Hadfield steel displays good wear resistance due to its high cold work ability. However, Hadfield steel is not corrosion resistant.
Applications of SIDUR 3401 Plates :
Components for dredgers and crushers, conveying machines: crushing’s jaws, impact wedges, linings, etc.
Hardening of SIDUR 3401 Plates :
Harden from a temperature of 1000-1050 Degree C followed by water quenching. Hardness after quenching is about 200 HB
Forging of SIDUR 3401 Plates :
Hot forming temperature: 1050-850 Degree C
Machinability of SIDUR 3401 Plates :
The machinability of this steel is poor
Mechanical Properties of SIDUR Plates
| Thickness (mm) | Width (mm) | Length (mm) | Yield strength (minimal) Re (MPa) | Tensile strength Rm (MPa) | Elongation (minimal) A5 (%) | |
| SIDUR 250 | 8 to 60 | 1000 to 2500 | 2000 - 12000 | 750 | 940 | 15 |
| SIDUR 300 | 8 to 60 | 1000 to 2500 | 2000 - 12000 | 820 | 1030 | 15 |
| SIDUR 400 | 8 to 110 | 1000 to 2500 | 2000 - 12000 | 900 | 1300 | 12 |
| SIDUR 450 | 8 to 100 | 1000 to 2500 | 2000 - 12000 | 1100 | 1450 | 10 |
| SIDUR 500 | 8 to 100 | 1000 to 2500 | 2000 - 12000 | 1300 | 1650 | 8 |
| SIDUR 350 hi temp | 6 to 60 | 1000 to 2500 | 2000 - 12000 | 660 | 1000 | 10 |
| SIDUR 3401 | 2 to 60 | 1000 to 2500 | 2000 - 12000 | 350 | 800 - 1000 | 30 |
Special Steels :
| Grade name | W. NR. | C | Si | Mn | Cr | Mo | Ni | V | STRENGTH (N/mm2) |
| SINOXX E770 | 1.4021 | 0,21 | 0,35 | 0,50 | 13,00 | 0,60 | 700 – 850 | ||
| 800 – 950 | |||||||||
| SINOXX 4922 | 1.4923 | 0,20 | 0,30 | 0,50 | 11,30 | 0,90 | 0,60 | 0,30 | 800 – 950 |
| 900 – 1050 | |||||||||
| SINOXX 4903 | 1.4903 | 0,10 | 0,35 | 0,45 | 9,00 | 1,00 | 0,20 | 585 – 850 | |
| SINOXX 4057 | 1.4057 | 0,18 | 0,40 | 0,60 | 16,00 | 2,30 | 800 – 1050 | ||
| SIQUAL 7765 | 1.7765 | 0,33 | 0,25 | 0,50 | 3,00 | 0,90 | 0,20 | 880 – 1080 | |
| SIQUAL 7380 | 1.738 | 0,14 | 0,30 | 0,50 | 2,30 | 1,00 | 430 – 670 | ||
| SIDUR 3401 | 1.3401 | 1,20 | 0,40 | 13,00 | 780 – 1130 |
