AM/NS ROCKSTAR 400 Plates & Sheets
Rockstar is the range of high hardness, low alloyed martensitic steels. This abrasion resistant steel obtains hardness through intense water quenching and tempering process. Rockstar plates are available in three nominal hardness levels: 400, 450 and 500 BHN. Rockstar plates are optimised to provide high hardness, toughness, good formability.
We M/s New Arise Metal have wide range of ready stock in Rockstar 400, Rockstar 450 & Rockstar 500 Plates & Sheets from AM/NS India (ArcelorMittal Nippon Steel India)
For any requirment you can contact us.
Grade Designation :
| Product Category | Hardness Level |
| Rockstar 400 | 360-430 BHN |
| Rockstar 450 | 425-475 BHN |
| Rockstar 500 | 450-540 BHN |
Capability & Dimensions :
| Product Category | Thickness Range |
| Rockstar 400 | 6 - 80 mm |
| Rockstar 450 | 6 - 50 mm |
| Rockstar 500 | 6 - 50 mm |
Up to 3500mm, higher width can be provided with case-to-case basis, depending on thickness.
Delivery Conditions :
- Quenched / Quenched and tempered:
The plates are delivered with sheared or thermally cut edges. Untrimmed edges can also be delivered with prior agreement.
Plates can be delivered in shot blasted and primer coated surface condition.
Tensile Properties :
Tensile properties given in below table are typical values normally observed in 20mm thick plate for reference purpose only.
| Grade & Thickness | Yield strength (Min-MPa) | Tensile strength (Min-MPa) | % Elongation (GL = 50 mm) | Charpy V-Notch Impact toughness (Min) |
| Rockstar 400 | 1000 | 1250 | 12 | 27 Joules min @ -40℃ |
| Rockstar 450 | 1100 | 1350 | 10 | 27 Joules min @ -20℃ |
| Rockstar 500 | 1200 | 1450 | 8 | 27 Joules @ 0℃ |
* Tensile Properties shall be provided based on case-to-case properties
